Carbon fiber bar
High Strength · Corrosion Resistant · Ultra-Light · The New Choice for Reinforcement
Key Features
-
Ultra-High Tensile Strength: 5–7 times the strength of conventional steel rebar
- Corrosion Resistance: Unaffected by chloride ions, acids, and alkaline environments; longer service life
- Lightweight and Efficient: Only 1/4 the weight of steel rebar; easier transportation and installation
- Non-Magnetic / Non-Conductive: Suitable for medical, electrical, radar, and other special environments
- Dimensional Stability: Minimal thermal expansion; suitable for extreme environmental changes
Applications
- Reinforcement of concrete beams, slabs, and columns.
- Seismic strengthening of bridges
- Corrosion-resistant reinforcement of marine structures
- Strengthening of tunnels/subways/piers
- Replacement of steel rebars in medical, power, and high magnetic field environments
Specifications
Color：Black
Diameter：6/8/10 mm
Packaging：100m/Roll
Storage：Store in a dry place and without direct sunlight at a temperature between -5℃ and +35℃
Shelf life：2 years
Density：1.6 g/cm³
Fiber Content：Min 68%
Dry Fiber Tensile Strength：4900 MPa
Tensile Strength：2000 MPa EN 2561
Tensile Elastic Modulus：165 GPa EN 2561
Documents
FSL 1405, FSL 1410
Carbon Fiber Plate 1.4mm*50mm/100mm
FSL 1205, FSL 1210
Carbon Fiber Plate 1.2mm*50mm/100mm
FSE 362 Adhesive
Carbon Fiber Plate Adhesive
Brochure CFRP System
Carbon Fiber Plate, Carbon Fiber Plate Adhesive
Installation Instruction
Carbon Fiber Plate, Carbon Fiber Plate Adhesive
Software-Fidstrong FRP Designer
Calculate Capacity Online
- Online tool to calculate FRP-strengthened concrete capacity.
- Based on ACI 440.2-23 and Eurocode 2 standards.
- Input member size and reinforcement layout easily.
- Get instant results for safe, optimized designs.
- Built for carbon fiber retrofitting projects.
- No installation needed—access anytime online
