FSL-Carbon Fiber Plate
High Strength Carbon Fiber Plate for structural strengthening. Fidstrong’s FSL-Plate offers superior performance and durability, ensuring reliable reinforcement for various construction applications.
Key Features
- Very high tensile strength
- Excellent fatigue resistance
- Corrosion-resistant and highly durable in harsh environments
- Lightweight, with minimal impact on structural dead load and building height
- Supplied in any length – no overlapping required
- Easy to install, including overhead and in tight intersections
- Fast application with minimal downtime
- No noise or vibration during installation
- Simple, cost-effective strengthening solution
Applications
- Flexural Strengthening of Beams & Slabs: Reinforces concrete members to increase moment capacity and reduce deflection.
- Shear Strengthening of Structural Elements: Applied to enhance shear resistance in beams, particularly at support zones.
- Column Confinement and Load-Bearing Capacity Upgrade: Used to wrap columns to improve compressive strength and seismic performance.
- Bridge & Infrastructure Rehabilitation: Effective in upgrading aging bridges, tunnels, and viaducts without adding significant dead load.
Specifications
Fidstrong carbon fiber plates are available in a range of sizes and performance options to meet different structural strengthening requirements:
Thickness options: 1.2 mm and 1.4 mm
Width options: 50 mm, 100 mm, 150 mm
Length per roll: 100 meters (custom lengths available upon request)
Fiber type: High-performance 12K or 24K carbon fiber
Tensile strength: 2,400 MPa to 3,100 MPa
Elastic modulus: 160 GPa to 210 GPa
Custom specifications including thickness, width, roll length, fiber type, and mechanical performance can be tailored based on project requirements.
Documents
FSL 1205, FSL 1210
Carbon Fiber Plate 1.2mm*50mm/100mm
FSL 1405, FSL 1410
Carbon Fiber Plate 1.4mm*50mm/100mm
FSE 362 Adhesive
Carbon Fiber Plate Adhesive
Brochure CFRP System
Carbon Fiber Plate, Carbon Fiber Plate Adhesive
Installation Instruction
Carbon Fiber Plate, Carbon Fiber Plate Adhesive
Software-Fidstrong FRP Designer
Calculate Capacity Online
- Online tool to calculate FRP-strengthened concrete capacity.
- Based on ACI 440.2-23 and Eurocode 2 standards.
- Input member size and reinforcement layout easily.
- Get instant results for safe, optimized designs.
- Built for carbon fiber retrofitting projects.
- No installation needed—access anytime online
