FidStrong Steel Jacket Grouting Adhesive
A two-component, high-flow epoxy grout designed for structural reinforcement using steel jacketing or embedded void injection. Provides excellent compressive strength, bonding performance, and durability for restoring or enhancing structural elements.
Key Features
- Excellent fluidity for pouring or injection into steel jackets
- High compressive and bonding strength
- Strong adhesion to both steel and concrete
- Non-shrink, solvent-free, long-term stability
- Resistant to vibration, fatigue, and environmental stress
- Suitable for both dry and slightly damp substrates
Applications
- Steel jacket column strengthening
- Void filling between steel sleeve and concrete
- Repair and retrofitting of deteriorated columns and piers
- High-load grouting in bridges, piers, and industrial foundations
- Shear and confinement strengthening using steel casings
Specifications
High-strength epoxy adhesive for bonding steel slabs to concrete structures
Type: Two-component epoxy grout
Mixing Ratio: 2:1
Color: light Gray (customizable)
Viscosity:Low (self-leveling and pumpable)
Pot Life: 30–45 minutes at 25°C
Initial Cure: in 6–8 hours;
Full Cure: 48 hours
- Compressive Strength: >70 MPa
Shear Strength: >12 MPa (steel slab to concrete)
Bond Strength to Concrete: >2.5 MPa
Packaging: 3kg, 10kg, 20kg sets (custom packaging available)
Custom specifications including packing, color and mechanical performance can be tailored based on project requirements.
Documents
FSE 682
Steel Jacket Grouting Adhesive
Steel Jacket Grouting
Steel Jacket Grouting Adhesive
Installation Instruction
Steel Jacket Grouting Adhesive
